Introduction
Product Features
Application: high pole lamp below 40 meters
Color: Silver (customized)
1.Compact size, lightweight, low wind resistance, high brightness, and exceptional light control capabilities.
2.Provides an illuminance of 100lm/cm² and a light efficiency of 200lm/kg.
3.Offers outstanding light efficiency with a whole lamp efficiency of 140-150lm/W, making it a suitable replacement for standard LED floodlights of 1500W in the market while providing the same illuminance level.
4.Boasts an extra-long lifespan with a 5-year global outdoor warranty.
5.Utilizes COB light sources, resulting in over 60% energy savings compared to traditional fixtures at the same illuminance.
Parameter
Item | AD-TG08100W/ AD-TG08400W/ AD-TG081000W |
Power(W) | 100W/400W/1000W |
Voltage(V) | 100-265V/AC/50-60HZ |
CRI | 70-90 Optional |
Lumen | 140±10 lm/W |
Angle | 30 |
Operating Temperature | (-40℃-60℃) |
Lamp Size | 175*153*150mm/ 320*305*230mm/ 480*465*290mm |
LED Lifetime | 85000hrs |
Material | Aluminum+Lens |
IP | IP67 |
Warranty | 5 Years |
Light distribution curve
30 DEG
60 DEG
90 DEG
80x120 DEG
